TypeBox

JSON Schema Type Builder with Static Type Resolution for TypeScript



npm version Downloads Build License

Install

$ npm install typebox

Usage

import Type from 'typebox'

const T = Type.Object({                             // const T = {
  x: Type.Number(),                                 //   type: 'object',
  y: Type.Number(),                                 //   required: ['x', 'y', 'z'],
  z: Type.Number()                                  //   properties: {
})                                                  //     x: { type: 'number' },
                                                    //     y: { type: 'number' },
                                                    //     z: { type: 'number' }
                                                    //   }
                                                    // }

type T = Type.Static<typeof T>                      // type T = {
                                                    //   x: number,
                                                    //   y: number,
                                                    //   z: number
                                                    // }

Overview

Documentation

TypeBox is a runtime type system that creates in-memory JSON Schema objects that infer as TypeScript types. The schematics produced by this library are designed to match the static type checking rules of the TypeScript compiler. TypeBox offers a unified type system that can be statically checked by TypeScript and validated at runtime using standard JSON Schema.

This library is designed to allow JSON Schema to compose similar to how types compose within TypeScript’s type system. It can be used as a simple tool to build up complex schematics or integrated into REST and RPC services to help validate data received over the wire.

License: MIT

Contents

Type

Documentation

TypeBox provides many functions to create JSON Schema types. Each function returns a small JSON Schema fragment that can be composed into more complex types. TypeBox includes a set of functions that are used to construct JSON Schema compliant schematics as well as a set of extended functions that return schematics for constructs native to JavaScript.

Example

The following creates a JSON Schema type and infers with Static.

import Type from 'typebox'

const T = Type.Object({                             // const T = {
  x: Type.Number(),                                 //   type: 'object',
  y: Type.Number(),                                 //   required: ['x', 'y', 'z'],
  z: Type.Number()                                  //   properties: {
})                                                  //     x: { type: 'number' },
                                                    //     y: { type: 'number' },
                                                    //     z: { type: 'number' }
                                                    //   }
                                                    // }

type T = Type.Static<typeof T>                      // type T = {
                                                    //   x: number,
                                                    //   y: number,
                                                    //   z: number
                                                    // }

Schema options can be passed on the last argument of any given type.

const T = Type.String({                             // const T = {
  format: 'email'                                   //   type: 'string',
})                                                  //   format: 'email'
                                                    // }

const S = Type.Number({                             // const S = {
  minimum: 0,                                       //   type: 'number',
  maximum: 100                                      //   minimum: 0,
})                                                  //   maximum: 100
                                                    // }

Value

Documentation

The Value submodule provides functions for validation and other typed operations on JavaScript values. It includes functions such as Check, Parse, Clone, Encode, and Decode, as well as advanced functions for performing structural Diff and Patch operations on dynamic JavaScript values.

import Value from 'typebox/value'

Example

The following uses the Value module to Parse a value.

const T = Type.Object({
  x: Type.Number(),
  y: Type.Number(),
  z: Type.Number()
})

const A = Value.Parse(T, {                          // const A: {
  x: 1,                                             //   x: number,
  y: 0,                                             //   y: number,
  z: 0                                              //   z: number
})                                                  // } = ...

Script

Documentation

TypeBox includes a runtime TypeScript DSL engine that can transform TypeScript syntax into JSON Schema. The engine is implemented at runtime and within the TypeScript type system.

// ----------------------------------------------------------
// Script
// ----------------------------------------------------------
const T = Type.Script(`{
  x: number,
  y: string,
  z: boolean
}`)

// ----------------------------------------------------------
// Reflect
// ----------------------------------------------------------
T.type                                              // 'object'
T.required                                          // ['x', 'y', 'z']
T.properties                                        // { x: ..., y: ..., z: ... }

// ----------------------------------------------------------
// Computed
// ----------------------------------------------------------
const S = Type.Script({ T }, `{
  [K in keyof T]: T[K] | null
}`)

// ----------------------------------------------------------
// Inference
// ----------------------------------------------------------
type S = Type.Static<typeof S>                      // type S = {
                                                    //   x: number | null,
                                                    //   y: string | null,
                                                    //   z: boolean | null
                                                    // }

Schema

Documentation

The Schema submodule is a low level JSON Schema spec compliant validation system that supports Drafts 3 through to 2020-12. This validation system is decoupled from both Type.* and Value.* submodules and is designed to be an ultra lightweight, high performance alternative to Ajv for compiling and validating with native JSON Schema.

import Schema from 'typebox/schema'

Example

The following uses the Schema submodule to compile and parse from JSON Schema.

// ----------------------------------------------------------
// Compile
// ----------------------------------------------------------
const C = Schema.Compile({
  type: 'object',
  required: ['x', 'y', 'z'],
  properties: {
    x: { type: 'number' },
    y: { type: 'number' },
    z: { type: 'number' }
  }
})

// ----------------------------------------------------------
// Parse
// ----------------------------------------------------------
const R = C.Parse({  x: 0, y: 0, z: 0 })            // const R: {
                                                    //   x: number,
                                                    //   y: number,
                                                    //   z: number
                                                    // } = ...

Versions

TypeBox provides two distinct versions that span two generations of the TypeScript compiler.

Version 0.x

$ npm install @sinclair/typebox                     # 0.x - LTS    | TS 4-6

Developed against TypeScript 4-6 and maintained under Long Term Support (LTS) for existing infrastructure on the 0.x revision line. ESM and CJS compatible.

Version 1.x

$ npm install typebox                               # 1.x - Latest | TS 7 Native

Developed against the TypeScript 7 native compiler with advanced type inference and JSON Schema 2020-12 compliant validation, with backwards compatibility for 0.x types. ESM only.

Additional

The 1.x version is recommended for most new projects and is the active development line that targets optimizations enabled by the TypeScript 7 native compiler. The 0.x version is maintained under LTS for environments requiring CJS and ESM compatibility as well as support for older TypeScript compiler versions. For issues relating to 0.x please submit them to the TypeBox 0.x repository.

Contribute

TypeBox is open to community contribution. Please ensure you submit an issue before submitting a pull request. The TypeBox project prefers open community discussion before accepting new features.
